Model: HY10W-24,HY10W-27,HY10W-30,HY10W-33,HY10W-36

Rated Voltage: 24KV,27KV,30KV,33KV,36KV

Maximum Continuous Operating Voltage (MCOV): 19.5KV,22.0KV,24.4KV,27.5KV,29.0KV

1/4μs Lighting Current Impulse: 82.0KV,92.0KV,102KV,112KV,123KV

8/20μs Lighting Current Impulse: 72KV,81KV,90KV,99KV,108KV

30/60μs Switching Current Impulse: 62.0KV,69.8KV,79.0KV,86.7KV,92.4KV

2000μs Rectangular Wave Current Impulse Withstand : 250A,250A,250A,250A,250A,250A

4/10μs High Current Impulse Withstand: 100KA,100KA,100KA,100KA,100KA,100KA
