Model: HY10W-15, HY10W-18

Rated Voltage: 15KV, 18KV

Maximum Continuous Operating Voltage (MCOV): 12.7 KV, 15.3KV

1/4μs Lighting Current Impulse: 51.0KV, 61.5KV

8/20μs Lighting Current Impulse: 45KV, 54KV

30/60μs Switching Current Impulse: 38.5KV, 46.2KV

2000μs Rectangular Wave Current Impulse Withstand : 250A,250A

4/10μs High Current Impulse Withstand: 100KA,100KA
